Xtreme-CatTM

Reliable Performance In Xtreme Environments

Our Underwater Data Network/Power Composite Cables are extremely rugged yet flexible, with water-blocked construction. Designed for underwater use with high-speed network data, video, and sensor equipment, these cables are suitable for bottom-laid, vertical deployment and ROV applications.

Xtreme-Grade Jacketing

Our Xtreme-Cat® 5e 4 pair stranded conductors meet or exceed TIA 568-B. This underwater video cable features Winchester’s specially formulated “Xtreme-grade” flexible polyurethane jacket for easier payout, tighter bends, and better tractor control with extremely low coefficient of friction.

Custom for Your Applications

Winchester offers a set of standard part numbers, as well as custom cable configurations to fit your applications needs.

Key Features

  • Max Depth Rating of 200m
  • Extreme ruggedness, yet fl exible water-blocked construction
  • Cables can be used for bottom-laid, vertical deployment, winch systems, and ROV applications
  • Xtreme-Cat® 5e 4 pair stranded conductors meet or exceed TIA 568-B
  • Specially formulated “Xtreme-grade” flexible polyurethane jacket for easier payout, tighter bends, and better tractor control with extremely low coefficient of friction

Technical Specifications

  • Designs available to withstand pressures up to 10,000 PSI
  • Strength ratings up to 50K lbs
  • Power Components: 5C – 28AWG
  • Data Components: Cat 5e – 24AWG
  • Break Strength: 0 lbs. – 1,200 lbs.
  • Diameter (inch): 0.325 in – 0.700 in
  • Weight (lbs/1000 ft): 47 – 297

Related Series

Cross section of Xtreme Green cable made by Winchester Interconnect
Cross section of X-Marine cable made by Winchester Interconnect
Cross section of Xtreme light cable made by Winchester Interconnect
