Established Brand Portfolio

Winchester draws from the technical expertise of high quality, reliable RF brands such as TRU-Win® and Dynawave to meet the most demanding applications in aerospace and defense, industrial, semiconductor, medical and other commercial industry markets. Winchester’s formidable lineup of RF & Microwave flexible, conformable, and semi-rigid cable solutions can address your most challenging requirements across the RF frequency and power spectrums.

Broad Spectrum of Power and Frequency

Through superior design and manufacturing techniques, Winchester offers some of the broadest-frequency, highest-power, lowest-loss, most phase/amplitude-stable, and highest-flexibility products on the market. Winchester RF cable means quality across the broadest spectrum of power and frequency, from 50 kilowatts to 110 GHz.

Standard and Custom Configurations

In addition to our standard offering, our experienced engineering team is accustomed to collaborating with customers on custom solutions with unique requirements.

RF & Microwave Cable Assemblies Feature

Key Features

  • Ansys RF Modeling: HFSS & Electromagnetic Suite
  • In-house machining, assembly, and test capabilities
  • Electrical – Mechanical – Environmental design features:
    • Phase matching, stability, and  tracking
    • MIL-STD-348 and custom connector interfaces
    • High power / voltage insulators (multi-paction)
    • TRUtie^™ – robust axial and torsional strain relief
    • MIL-STD-810 & MIL-STD-202 environmental designs

Cable Brand Portfolio

  • ArcTite®
  • DynaFlex®
  • DynaTest™
  • PhaseTite®
  • TRUtest™
  • TRUcore™
  • TRUflex™ PWR
  • Haverhill Cable
